Complete DIY 2GR swap package

£3,311.00

Compare at £4,514.00

Quantity

Are you tired of not knowing what parts you need to do a proper 2GR V6 swap in your SW20 MR2? Shopping through multiple websites ordering parts from all over the place to try to get everything you need? Well we have decided to put together a complete package! Just click one button, supply an engine and you're all set!

Included in this kit:

2GR engine wiring harness made by Wiregap. This requires no core harness, and will work on any SW20 MR2
TCS Motorsports Tubular Header set
TCS Motorsports Y-pipe kit
TCS Motorsports muffler system (your choice of 2 variants)
HUX Racing 2GR Motor mount
ATS Racing Coolant fill port
Frankenstein Motorworks DBW pedal kit
OEM Drive by wire gas pedal
ATS Racing Tuned ECU
TCS Motorsports 3" Air intake kit with filter
TCS Motorsports 2GR fuel kit (fpr, fuel lines, fittings)
Correct coolant temperature sensor
Correct serpentine belt for a/c or no a/c
Correct radiator cap for 2GR
TCS Motorsports 2GR Coolant Hose kit w/ clamps
TCS Motorsports silicone coolant caps (only needed on some variants of 2GR)
M12x1.25 Helicoil kit with extra inserts

IF YOUR CAR IS A JDM RIGHT HAND DRIVE MODEL MR2, THIS KIT WILL WORK FOR YOU CAR, BUT WE WILL SUPPLY YOU WITH A DIFFERENT DRIVE BY WIRE PEDAL. IF YOU ORDER THIS KIT AND YOUR CAR IS RIGHT HAND DRIVE, PLEASE EMAIL US AT SALES@TCSMOTORSPORTS.COM IMMEDIATELY AFTER ORDERING AND LET US KNOW THE ORDER NUMBER, AND THAT YOUR CAR IS RIGHT HAND DRIVE. THIS WAY WE CAN ENSURE WE SHIP YOU THE CORRECT PEDAL FOR YOUR SETUP!

Please note: This is all assuming you have sourced a 2GRFE Engine that has all of the required sensors still on the engine. Most engines that we purchase here at TCS are missing things like the alternator, o2 sensors, and MAF sensor. Here are the part numbers we use for those items if your engine did not come with them:

Alternator : Denso 2100657 (buy denso please)

O2 sensor : Denso 2349008 (you will need 2 of these, buy denso please)

MAF Sensor: 22204-28010 (buy OEM, they can be found on ebay very affordably)

Nearly all of these parts are kept in stock at all times OTHER than the wiring harness. Sometimes we have wiring harnesses in stock, and sometimes there is a lead time. If you are in a hurry, please contact us before ordering to get lead times on the wiring harness.

As far as the options:

ADD A/C PACKAGE: Selecting this, we will ship you a brand new denso a/c compressor compatible with the 2GR, along with the correct TCS Motorsports a/c lines to fit your chassis year. Your old mr2 a/c compressor will NOT work.
ADD Clutch/FLYWHEEL PACKAGE: Selecting this, we will ship you the correct clutch and flywheel package for your setup. This consists of a Clutchmasters Aluminum Flywheel, Clutchmasters FX250 clutch kit, OEM flywheel bolts, and OEM pressure plate bolts. If you select you have a turbo model, we will also include the Frankenstein Motorworks Axle carrier brace that is required if you are using turbo model E153 transmission
